Rocking Armature Transducer BE46.5x17-150-YX 12KB Al
Rocking armature Transducer 46.5mm diameter, 24Vp-p rated voltage, 22 ohm coil resistance , 300-3400KHz resonant frequency , with or without wire, RoHS compliant
Product Details
|
No.
|
Item
|
Specifications
|
|
1
|
Product name
|
Minimum SPL 95dBand sensitivity 120db electro magnetic alarm
|
|
2
|
Product type
|
BE46.5*17-150-YX 12KB Al
|
|
3
|
Operating temperature
|
-40~+85℃
|
|
4
|
Sensitivity(1KHz)
|
120±3 dB
|
|
5
|
Frequency range
|
300~3400Hz
|
|
6
|
Rated Voltage
|
24V
|
|
7
|
Coil Resistance(20℃)
|
22ohm±10%
|
